Հեղուկ արմատների հոսքի չափիչ

Product Standard

JB/T9242-2015 (General Technical Specifications for Positive Displacement Flowmeters)

Explosion-proof Mark

Exd II CT6

Flange Standard

DN, ANSI, JIS

Protection Class

IP66

Accuracy Grades

0.5%, 0.3%, 0.2%

Ambient Temperature

-25°C to +60°C

Environmental Temperature

Electronic Counter (Standard): -25°C to +60°C

Mechanical Counter (Optional): -43°C to +60°C

Model

Shell, Front & Rear Cover

Cover Plate

Liquid Roots

Shaft

Bearing

Nominal Pressure (MPa)

LL-AL

Cast Iron

Cast Iron

Aluminum Alloy

Stainless Steel

Rolling Bearing

0.6, 1.0, 1.6

LL-EL

Cast Steel

Cast Iron

Aluminum Alloy

Stainless Steel

Rolling Bearing

DN80↓ 4.0 DN100↑ 2.5

LL-LL

Aluminum Alloy

Cast Iron

Aluminum Alloy

Stainless Steel

Rolling Bearing

0.6, 1.0, 1.6

Note

Special materials available upon request and can be customized for specific applications

Nominal Diameter (mm)

Fluid Viscosity (mPa·s)

2.0~150

0.6~2.0

2.0~150

0.6~2.0

2.0~150

0.6~2.0

25

0.6~6

1.2~6

1.2~6

1.5~6

1.5~6

2~6

40

1.6~16

3.2~16

3.2~16

4~16

4~16

5~16

50

2.5~25

5~25

5~25

6~25

6~25

8~25

80

6~60

12~60

12~60

15~60

15~60

20~60

100

10~100

20~100

20~100

25~100

25~100

33~100

150

25~250

50~250

50~250

60~250

60~250

80~250

Accuracy Grade

0.5

0.3

0.2

Model

L

H

I

B

C

D

D1

N-Φ

Weight (kg/unit)

LL-AL25.06 Thread

180

297

75

110×110

148

G1¼″ (Pipe thread)

8

LL-AL25.06 Flange

φ115

φ85

4-φ14

10

LL-AL40.1

240

320

88

φ170

170

φ150

φ110

4-φ18

21

LL-AL50.1

265

335

97

φ190

185

φ165

φ125

4-φ18

26

LL-AL80.1

265

394

122

φ246

248

φ200

φ160

8-φ18

40

LL-AL100.1

350

484

164

φ305

335

φ220

φ180

8-φ18

88

LL-AL150.1

560

602

232

φ440

455

φ285

φ240

8-φ22

202

Model

L

H

I

B

C

D

D1

N×Φ

Weight (kg/unit)

LL-EL25.3 Thread

180

297

75

120×120

148

G1¼″ (Pipe thread)

10

LL-EL25.3 Flange

φ115

φ85

4-φ14

LL-EL40.4

240

320

88

φ170

170

φ150

φ110

4-φ18

30

LL-EL50.4

360

370

105

φ226

222

φ165

φ125

4-φ18

41

LL-EL80.4

360

405

128

φ256

258

φ200

φ160

8-φ18

52

LL-EL100.3

450

482

167

φ334

338

φ235

φ190

8-φ22

110

LL-EL150.3

560

602

232

φ455

458

φ300

φ250

8-φ26

215
